The 900 mobile engine stand provides a secure and stable support for the tearing down and rebuilding diesel engines up to 5,000 lbs.

Features:

• Gives the mechanic a safer, more productive working environment.
• Provides a secure, stable support for the engine at a comfortable working height. Makes servicing and rebuilding far easier.
• Minimizes the possibility of engine damage due to positioning and re-positioning of the engine on work bench or floor. Keeps the engine and work area cleaner.
• Lowers costs by reducing tear-down and reassembly time. A 20% saving in time is typical.
• Fast and easy positioning | 2-Plane engine positioning (vertical and horizontal) provides a 360° swing radius and optimum engine accessibility. Hand crank with speed reducer makes positioning easy.
• Solid working stability | Angled leg construction provides a steady stand and enables the mechanic to get closer to the work
• Convenient work height | Makes engine rebuilding and servicing easier, faster and safer.
• MADE IN THE USA

Engine Adapters (Sold Separately)

CATERPILLAR
Adapter 971 | 1140, 1145, 1150, 1160, 3145, 3160, 3208 Call for pricing
Adapter 973 | C-15, 1673, 1674, 1693, 3304, 3306, 3406, 3406E
Adapter 984 | 3408 (V8), 3412 (V8)
CUMMINS
Adapter 552 | 855 CID (NH, NT & NTC engines including N-14), 927 CID (250 & 270 Engines)
Adapter 901 | ISX 15
Adapter 906 | C-Series
Adapter 957 | V-378, V-504, V-555, V6-140, V8-170, V8-185, V8-210
Adapter 959 | V-903, VT-903, V6-200, V8-265, V8-350
Adapter 993 | L-10, M-11
Adapter 994 | B Series
DETROIT DIESEL
Adapter 551 | 71 Series 3, 4 & 6 Inline
Adapter 907 | Series 60
Adapter 945 | 71 Series 6V & 8V, 92 Series 6V & 8V
JOHN DEERE
Adapter 988 | 3164, 3179, 4219, 4239D, 4239T, 4276D, 4276T, 6329, 6359D, 6359T, 6414D, 6414T
Adapter 992 | 4629, 6404, 6466A, 6466D, 6466T, 6531, 6619A
MACK
Adapter 981 | Engine MS 200 Call for pricing
Adapter 982 | Engine MS 300 Call for pricing
Adapter 985 | Engine 865, E6 w/serial #s starting 'IR' and later, E7, EM9, VB-1000
NAVISTAR
Adapter 916 | Engine T444E, 6.9 & 7.3 liter
Adapter 917 | Engine 2004-2006 MAXXFORCE DT466, 570, HT570 (I-313), 2007-2009 MAXXFORCE DT, 9, 10 (I-326), 2010 & Later MAXXFORCE DT, 9, 10 (I-334)
Adapter 970 | DT-408, DT-530, D & DT-312, D & DT-360, D & DT-414, D & *DT-466 (*up to 2004)
Adapter 973 | Engine MAXXFORCE 15
PERKINS
Adapter 952 | Engine 3.152, 4.203

Transmission Adapters (Sold Separately)

Adapter 976 | Allison AT-500 Series Call for pricing
Adapter 977 | Allison MT-600 Series Call for pricing
Adapter 979 | Allison HT-700 & C(LB)T-750 Call for pricing
Adapter 983 | Fuller (Eaton) RT Series (Twin Countershaft), Spicer Twin Countershaft Transmission except 7-speed Call for pricing

Universal Adapter (Sold Separately)

Adapter 952 | 1000 # Capacity attaches to rear of engine
